Product Features
01
Rotors are tested by the dynamic balancing,low vibrating and low noise.
02
Equipped with the SKF bearing,long service life.
03
Romovable operation door,and qucick-clamping pressing screen structure,convenient and quick replacement screen.
04
Equipped with the safety interlock device to ensure the motor cann’t start when the door is open.
05
Equipped with iron remover to prevent metal impurities from entering the crushing chamber.
06
The gap between the rotor and hammer can be adjusted,which can be adapted to livestock and poultry and aqua feed products.
Technical Parameters
| Model | ZNFS56*30 | 56*40 | 63*35 | 63*45 | 66*60 | 66*80 | 66*100 | 66*125 |
| Rotor Dia(mm) | 560 | 560 | 630 | 630 | 660 | 660 | 660 | 660 |
| Main Shaft Speed(r/min) | 2970 | 2970 | 2970 | 2970 | 2970 | 2970 | 2970 | 2970 |
| Chamber Width(mm) | 300 | 400 | 350 | 450 | 660 | 800 | 1000 | 1250 |
| Power(kw) | 18.5/22 | 22/30 | 30/37 | 37/45 | 55/75 | 90/110 | 132/160 | 160/200 |
| （t/h） | 1-3 | 1.5-3.5 | 2-5 | 3-6 | 8-12 | 12-16 | 15-20 | 18-25 |
Delivery Goods
We follow a standardized process: prepare order verificationequipmentfactory quality inspectionpacking list re-inspectionscientific packaging andtransportation to ensure safe and undamaged deliveryofequipment.
